High Precision Desktop Fiber Laser Jewelry Marking Machine Metal Engraving Cutting Machine For Metal Silver Gold

Main effects: 1, through the evaporation of laser light energy on the surface of the target material to expose the deep layer of the material; 2, through the laser light can lead to chemical and physical changes in the surface material and "engraved" the required pattern text; 3, through the laser light to burn part of the material, so as to show the required etching pattern, text.

Fiber laser marking machine is mainly composed of: fiber laser, galvanometer (marking head), software control board, industrial control computer, chassis cabinet, horizontal platform of releasing work parts, etc.

Features:

1.Fiber laser marking machine using fiber laser, life of up to 100,000 hours, stable and efficient.The beam quality is high, with a fundamental mode (TEM00) output and a focused spot diameter of less than 20um. The divergence Angle is 1/4 of that of a semiconductor pumped laser. The single line is thinner, especially suitable for fine and precise marking.

2. Small size, small power consumption, the power consumption of the whole machine is less than 500W; Built-in air-cooled cooling mode, abandoning the bulky water-cooled unit, occupies a smaller area, is easier to install, and truly saves energy and is portable.

3. High electro-optic conversion efficiency, simple to use, no optical adjustment or maintenance, compact structure, high system integration, less failure.

4. Without any maintenance, long service life, suitable for harsh environment work.

5. The processing speed is fast, 2-3 times that of the traditional marking machine, optical scanning galvanometer, laser repetition frequency is high, high-speed without distortion.

6. Fiber lasers are equipped with optical isolators to effectively shield reflected light, and can be operated on high-bright surface high-reflective materials such as gold, silver, copper, aluminum, and silicon, without deviating from the center of the field mirror, which greatly broadens the application field. And for different metals, it can play a certain color through the adjustment of frequency and energy.

7. Marking software is powerful, compatible with Coreldraw, AutoCAD and other software files; Support PLT, PCX, DXF, BMP, etc., can directly use SHX, TTF library; Support automatic coding, printing serial number, batch number, date, bar code, two-dimensional code, automatic jump number, etc., USB interface output control.
